IC 022, IC 022 PLUS

Pequeño equipo potente IC 022 EVO para limpieza fina

Los equipos profesionales eliminan la suciedad gruesa y fina, y son adecuados para empresas pequeñas,

Parámetros

Material

Carcasa: fibra de vidrio
Marco de rueda: acero inoxidable

Peso

Bajo peso: solo 19 kg

Capacidad

4 kg

Consumo de aire

1,1m³/min

Characteristics

Dry ice blasting has never been so affordable! Discover a new dimension of surface cleaning!

Dry ice cleaning is now also available to car workshops, car dealerships, all manufacturing or maintenance companies in any industry, big or small. We bring you a cost-effective alternative to traditional cleaning methods.

The unique design of the IC 022 EVO offers surprising flexibility, performance and power. The maintenance-free feeding system from ICS accepts both 1,5 mm and standard 3 mm dry ice pellets.

The excellent design of the blaster allows easy handling even in tight access spaces. The operation of the machine is easy and fast to get used to.

With IC 022 EVO you are equipped to manage very wide variety of cleaning tasks.

IC 022 EVO with its unique feeding system offers unrivalled performance at an unbeatable price.

3D view

Examples of use

For download

Dimensions	Consumption	Weight
Length: 528 mm	Dry ice: to 24 kg/h	Empty machine: 19 kg with the hose
Width: 296 mm	Compressed air: 1,1 m³/min. depending on the nozzle type	and blast gun
Height: 336 mm

Operating pressure	Hopper capacity	ISO 8573-1:2010 [1:4:1]
8 – 10 bar	4 kg	0,1 mg/m³ Particles Class: 1
		DTP 3°C Water Class 4
Material	Noise level	0,01 mg/m³ Class 1 oil 1
Casing: Fibreglass, Wheel frame: Stainless steel	65-85 dB(A) depending on the blasting
	pressure and the cleaned surface
Compressed air supply
NW 7.2 coupling, acc. ISO	Imput pressure
4414/EN 983 standard	up to 10 bar (145 PSI)
